Ainol NOVO7 Elf Unboxing & Disassembling Details

Discussion in 'McBub.com' started by af2000, Jan 20, 2012.

  1. af2000

    af2000 Member

    Joined:
    Dec 27, 2011
    Messages:
    28
    Likes Received:
    8
    Trophy Points:
    62
    Location:
    Shenzhen, Guangdong, China
    Tablet / Device:
    iPad 2, Samsung Galaxy S II, Teclast P76Ti, Zenithink ZT-280 C91
    Hi all, here are some pics showing what's inside Ainol NOVO7 Elf machine

    [​IMG]
    Ainol NOVO7 Elf
    [​IMG]
    Front
    [​IMG]
    Attachments
    [​IMG]

    [​IMG]
    circuit board
    [​IMG]
    7-inch 1024*600 Screen Model Number
    [​IMG]
    5-Point Touchscreen Model Number
    [​IMG]
    2MP front-facing camera
    [​IMG]
    Battery Capacity
    [​IMG]
    Vibration Motor & Speaker
    [​IMG]
    CPU





    P.S. Good News, Ainol NOVO7 Elf is available at McBub.com, only USD$146.99 Plus FREE SHIPPING


    More details about Ainol Novo 7 Elf :


    ModelAinol Novo 7 Elf
    Operation SystemGoogle Android 4.0 ICS
    CPUAllwinner A10 1.2GHz Cortex A8
    RAMDDR3 1GB
    Nand Flash8GB
    Screen 7 inch Capacitive Multi-Touch Screen, Resolution: 1024x600Pixels. 5-Point Touch
    WirelessWiFi 802.11b/g/n.
    WebcamFront 1.3MP
    G-sensor4 Way G-sensor
    Bluetooth No
    Graphics TypeIntegrated Graphics, Supports 1080P video (1920*1080)
    Input/Output Connectors
    Ports 1 x Mini USB OTG
    1 x TF Card slot
    1 x Earphone Jack
    KeysPower on/Off; Return; Menu.
    Power
    Battery3800mAH 7.4V Rechargeable Li-ion Battery
    Working Time5-6hours with Wi-Fi on. 6-7 hours with Wi-Fi off.
    Power Device AC Adapter Input 100/240V
    Device Specification
    Dimensions190X120X12mm
    Net WeightAbout 340g
    ColorBlack
    Software Performance
    Android Marketnot currently, Ainol will fix this problem soon
    Flash PlayerSupport Adobe Flash Player, but not support online flash video playback currently
    OfficeSupport MS Office Word, PPT, Excel
    GamingBuilt-in 3D Accelerator. Powerful 3D gaming
    EmailGmail, POP3/SMTP/IMAP4. Emailing is easier than ever before when there is network connection
    Multi-Media
    VideoAVI, MP4, FLV, 3GP, MKV, WMV (1080p) etc. Please note that some video formats may require additional downloaded software from the Android Market
    AudioMP3, WMA, OGG, AAC, WAV etc.
    PictureJPEG, PNG, BMP, GIF
    E-BookPDF, TXT etc.
    What's in the box1 X Tablet PC
    1 X USB Cable (connects to PC),Support Charge via USB Port
    1 X Earphone
    1 x Standard Charger
    1X Charger adapter as gift ( European Charger Standard, UK Standard, AU Standard )
    Additional Features1) Pre-installed Official Games: Angry Birds, Fruit Slice, Spider-Man, Straight Flush, The Last Deferder, Turbofly 3D, Wow Fish, etc
    2) Built-in 3D Accelerator (ideal for 3D gravity sensor games such as "Asphalt5").


    Attached Files:

    Last edited: Jan 20, 2012
    • Like Like x 2
  2. af2000

    af2000 Member

    Joined:
    Dec 27, 2011
    Messages:
    28
    Likes Received:
    8
    Trophy Points:
    62
    Location:
    Shenzhen, Guangdong, China
    Tablet / Device:
    iPad 2, Samsung Galaxy S II, Teclast P76Ti, Zenithink ZT-280 C91
    I'll keep updating this post with further review on Ainol NOVO 7 Elf :D

  3. sparkyar

    sparkyar Member

    Joined:
    Jan 24, 2012
    Messages:
    2
    Likes Received:
    0
    Trophy Points:
    60
    Hi, thank you for the disassembling pictures, what are the real specs for the battery? 3700mAh 3.7v like we see in the picture or 3800mAH 7.4V as you put in the details?

  4. HanzeeMan

    HanzeeMan Member

    Joined:
    Jan 19, 2012
    Messages:
    12
    Likes Received:
    1
    Trophy Points:
    62
    Location:
    Israel
    Tablet / Device:
    want to buy elf
    Any body buy from McBub yet?? Need some buyer feedback. What is the after purchase support like??
    Thanks in advance
    John

  5. af2000

    af2000 Member

    Joined:
    Dec 27, 2011
    Messages:
    28
    Likes Received:
    8
    Trophy Points:
    62
    Location:
    Shenzhen, Guangdong, China
    Tablet / Device:
    iPad 2, Samsung Galaxy S II, Teclast P76Ti, Zenithink ZT-280 C91
    thanks for the correction, the real battery capacity is 3700mAh 3.7v

  6. JotaSilva

    JotaSilva Member

    Joined:
    Jan 29, 2012
    Messages:
    12
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    Lisbon
    Tablet / Device:
    Ainol Novo 7 - Android 3.2 Honeycomb
    Hi
    What kind of USB Bluetooth Adapter do you recommend for Ainol Novo7?
    Regards
    JotaSilva

  7. af2000

    af2000 Member

    Joined:
    Dec 27, 2011
    Messages:
    28
    Likes Received:
    8
    Trophy Points:
    62
    Location:
    Shenzhen, Guangdong, China
    Tablet / Device:
    iPad 2, Samsung Galaxy S II, Teclast P76Ti, Zenithink ZT-280 C91
    sorry, none so far, I'll update if any external Bluetooth adapter is good for Novo7 elf.

    • Like Like x 2
  8. JotaSilva

    JotaSilva Member

    Joined:
    Jan 29, 2012
    Messages:
    12
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    Lisbon
    Tablet / Device:
    Ainol Novo 7 - Android 3.2 Honeycomb
    Hi af2000

    My tablet is not an ELF.
    It's a Ainol Novo7 Basic 3.2 Honeycomb.
    There is not an external Bluetooth adapter for this tablet?

    Regards

  9. af2000

    af2000 Member

    Joined:
    Dec 27, 2011
    Messages:
    28
    Likes Received:
    8
    Trophy Points:
    62
    Location:
    Shenzhen, Guangdong, China
    Tablet / Device:
    iPad 2, Samsung Galaxy S II, Teclast P76Ti, Zenithink ZT-280 C91
    So far novo7 basic doesn't support any Bluetooth adapter, either

    • Like Like x 2
  10. JotaSilva

    JotaSilva Member

    Joined:
    Jan 29, 2012
    Messages:
    12
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    Lisbon
    Tablet / Device:
    Ainol Novo 7 - Android 3.2 Honeycomb
    Hi af2000

    I intend to by a 32GB SDHC card to my Ainol Novo7 3.2 Honeycomb.
    Please inform what kind of Class SDHC do you recommend. Class 4, 6 or 10?

    Regards
    Jota

  11. af2000

    af2000 Member

    Joined:
    Dec 27, 2011
    Messages:
    28
    Likes Received:
    8
    Trophy Points:
    62
    Location:
    Shenzhen, Guangdong, China
    Tablet / Device:
    iPad 2, Samsung Galaxy S II, Teclast P76Ti, Zenithink ZT-280 C91
    Hi JotoSilva,
    Class 4: 4 MB/sec (32 Mbit/sec), Can meet the needs to watch ordinary MPEG4 MPEG2 movies, SDTV, Medium Resolution Digital Cameras and Standard Definition Camcorders
    Class 6: 6 MB/sec (48 Mbit/sec), To meet the SLR camera shooting and the use of specialized equipment requirements, High Resolution Digital Cameras and High-Definition Digital Camcorders
    Class 10: 10 MB/sec (80 Mbit/sec), High Resolution Digital Cameras and High-Definition Digital Camcorders

    so I think SDHC Class 4, 4 MB/sec (32 Mbit/sec) is enough for you to use on your Novo7 Basic tablet.

    • Like Like x 2
  12. JotaSilva

    JotaSilva Member

    Joined:
    Jan 29, 2012
    Messages:
    12
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    Lisbon
    Tablet / Device:
    Ainol Novo 7 - Android 3.2 Honeycomb
    Hi af2000

    Thanks for your advices and informations. They are very useful. You know that I'm new in Android OS. I bought a Ainol novo7 3.2, I like the tablet and it's functions, but I'm sad about apps on Android market.

    I apreciate if you can help on my questions bellow:

    1 - You know that are a lot of people with bad opinion about Novo7 Basic 3.2 Honeycomb, because MIPS chipset doesn't is not compatible with a lot of apps on Android Market. What is your opinion about this?

    2 - There is a solution that can solve the problem and permit to have access to a lot of apps on Android Market?

    3 - Is it possible to upgrade Novo7 Basic from 3.2 to 4.0?

    4 - There is any advantage to do the upgrade?

    Thanks in advance
    Jota

  13. af2000

    af2000 Member

    Joined:
    Dec 27, 2011
    Messages:
    28
    Likes Received:
    8
    Trophy Points:
    62
    Location:
    Shenzhen, Guangdong, China
    Tablet / Device:
    iPad 2, Samsung Galaxy S II, Teclast P76Ti, Zenithink ZT-280 C91
    Hi Jota, here is the latest Android 4.0.3 firmware for Novo7 Basic
    Download Link

    After upgrading to Android 4.0 on Novo7 Basic:

    Working: Wifi, GMail, Maps, Camera front & rear (inc 720 video), Web Browser, English Keyboard, Android Market, Supplied Games (Angry Birds & Turbo Fly), HTML 5 iPad browsing mode.

    Not Working: Adobe Flash, Google Calendar (seems to be a problem with authenticating more than one application to a single Gmail account).

    [h=2]Upgrade Guide[/h] Step 1
    Make sure the microSD card is fully formatted.

    Step 2
    Make sure your NOVO 7 Basic is fully charged.

    Step 3
    Switch it off.

    Step 4
    Insert the microSD card and Press and Hold (Volume + ) and Power button and release when you see the flash Ainol logo ( Not the first one ). That is it. Allow the update to run and do the rest.

  14. af2000

    af2000 Member

    Joined:
    Dec 27, 2011
    Messages:
    28
    Likes Received:
    8
    Trophy Points:
    62
    Location:
    Shenzhen, Guangdong, China
    Tablet / Device:
    iPad 2, Samsung Galaxy S II, Teclast P76Ti, Zenithink ZT-280 C91
    Sorry, above download link is not working, please go here:
    update_Basic_4.0.3.zip


    Click "电信下载" marked in red frame above, and you can start downloading, thank you.

    Last edited: Feb 4, 2012
    • Like Like x 2
  15. JotaSilva

    JotaSilva Member

    Joined:
    Jan 29, 2012
    Messages:
    12
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    Lisbon
    Tablet / Device:
    Ainol Novo 7 - Android 3.2 Honeycomb
    Hi af2000

    Thanks for your information about the upgrade from 3.2 to 4.0.
    But I would like to know what are the advantages on the upgrade for Ainol Novo7 Basic 3.2 to 4.0. What's the diference? What wil be the beneficts?

    Regards
