Telechips 7" with Integrated 3G

xaueious

Administrator
Staff member
Jul 9, 2010
3,483
436
Was sent this spec sheet for this generic tablet, to be branded the TM701 3G Wiipad


I might have first seen pictures of this as the HSG X6 in early August last year, even though that casing had the buttons shifted: http://bbs.mid123.com/thread-9631-1-1.html


Hardware Specification
Processor / Chipset : Telechip8902 720Mhz
Memory : DDR2 SRAM 256M Bytes
Display : 7” TFT XGA (800*480)
Display Control :Resistive Touch screen, Virtual keyboard
Storage : NAND Flash memory (2GB,4GB optional ); External SD Slot
Embedded Wi-Fi/BT connectivity: Wi-Fi: 802.11b/g/n; BT 2.1+EDR
3G Module WWAN connectivity (WCDMA/HSPA, CDMA EVDO, (built-in)
Audio : 1xSpeaker, Microphone 3.5mm (stereo) headset jack, FM transceiver
Camera :1.3M pixels
Controls :Power On/Off, Home, Volume + -
GPS :N
Sensors :Ambient Light Sensor, 3 axis Accelerometer, 4 direction
Inputs/Outputs :SD slot (SDIO), mini USB (host), HDMI, , earphone, DC jack usim card slot
Battery :Working time: 4 hours with wifi on Li-on 3000mAh

For about $180USD before shipping

Supposedly FCC, RoHS, and CE approved.


hiandroid

Member
Jul 21, 2010
25
1


7 inches Wiipad 3GTM701

Detailed Product Description
Hardware Specification
Processor / Chipset [FONT=&#23435]:[/FONT] Telechip8902 800Mhz
Memory[FONT=&#23435]:[/FONT] DDR2 SRAM 256M Bytes
Display [FONT=&#23435]:[/FONT] 7” TFT XGA (800*600)
Display Control [FONT=&#23435]:[/FONT]Resistive Touch screen, Virtual keyboard
Storage [FONT=&#23435]:[/FONT] NAND Flash memory (2GB,4GB optional ); External SD Slot
Embedded Wi-Fi/BT connectivity[FONT=&#23435]:[/FONT] Wi-Fi: 802.11b/g/n; BT 2.1+EDR
3G Module WWAN connectivity (WCDMA/HSPA, CDMA EVDO, (built-in)/UMTS2100/1900/850/CDMA800/1900mhz
Audio [FONT=&#23435]:[/FONT] 1xSpeaker, Microphone 3.5mm (stereo) headset jack, FM transceiver
Camera [FONT=&#23435]:[/FONT]1.3M pixels
Controls [FONT=&#23435]:[/FONT]Power On/Off, Home, Volume + -
GPS [FONT=&#23435]:[/FONT]N
Sensors [FONT=&#23435]:[/FONT]Ambient Light Sensor, 3 axis Accelerometer, 4 direction
Inputs/Outputs [FONT=&#23435]:[/FONT]SD slot (SDIO), mini USB (host), HDMI, , earphone, DC jack usim card slot
Battery [FONT=&#23435]:[/FONT]Working time: 4 hours with wifi on Li-on 3000mAh
Multimedia/software specification
Video Codecs [FONT=&#23435]:[/FONT] HW Video Codecs, HD720P TV-Out
Graphic [FONT=&#23435]:[/FONT] OpenGL ES 2.0, Open VG 1.1
eReader File Formats [FONT=&#23435]:[/FONT] PDF, 3rd party SW, TXT, HTML
Operating System [FONT=&#23435]:[/FONT] Android 2.1
Flash10.1 [FONT=&#23435]:[/FONT] N
Applications
Browser [FONT=&#23435]:[/FONT] Android Webkit
E-Mail [FONT=&#23435]:[/FONT] Android Email
IM/Social media : Face book, Twitter, etc.
eReader [FONT=&#23435]:[/FONT]Text to speech, Dictionary, Thesaurus
Productivity [FONT=&#23435]:[/FONT]Calendar, clock etc
LBS (navigation) [FONT=&#23435]:[/FONT]Google Map
Games [FONT=&#23435]:[/FONT]3rd Party
Applications/Content Store: Android Market Place, 3rd party
Mechanism
Dimension 195.120*147mm
Weight [FONT=&#23435]:[/FONT] 365g

Inclusions of 3GTM701 series:
1 Unit of TM701 7” Tablet PC
1 AC Charger (Power cord)
1 pc USB cord


l_n

Senior Member
Dec 28, 2010
788
99
Is this just something new or are you trying to sell me something?
