Visture V10 RK3066 CPU Mali 400 10.1 Screen

Discussion in 'Rockchip RK3066 Tablets' started by Dvalin21, Oct 22, 2012.

  1. Dvalin21

    Dvalin21 Senior Member

    Joined:
    Oct 28, 2010
    Messages:
    89
    Likes Received:
    8
    Trophy Points:
    180
    Location:
    NULL

    VISTURE

    V10 Technical Specifications[​IMG]

    Size, weight and material

    .Depth: 0.37 inch (9.3 mm)
    ·Height: 10.08 inches (256.5mm)
    ·Width: 6.73 inches (171.1 mm)
    ·Weight: 1.45 pound (0.66 kg)①
    ·Cover: Metal back cover silver, with black frame

    Display

    ·10.1-inch (diagonal) IPS display LED-backlit glossy widescreen Multi-Touch
    ·1280-by-800-pixel resolution
    ·Support for display of multiple languages and characters simultaneously

    Wi-Fi model

    ·Wi-Fi (802.11b/g/n)

    Location

    ·Google Map for position (Need access to internet)

    In the box

    ·V10
    ·USB data Cable, USB OTG Cable
    ·Power Adapter
    ·Documentation

    Capacity

    ·16GB~32GB Flash memory built in, Micro SD slot support up to 32G
    [​IMG]
    Processor

    ·Dual Cortex A9 1.5G CPU, Quad GPU Mail 400, 1G RAM DDR3

    Operation system

    Google Android 4.0

    Sensors

    ·G-Sensor

    Camera

    ·Front facing camera 2MP for video chat with Skype, QQ etc.
    ·Rear camera 2MP, 5MP optional.

    Apps

    ·Google play store (Android market), Gmail, Gmap, HD Video player, Music player, Camera app, Gallery, File Explorer,

    Audio/Video playback

    ·Frequency response: 20Hz to 20,000Hz
    ·Audio formats supported: MP3, WMA, WAV, OGG, FLAC, AAC, 8-48 KHz.
    ·Video: AVI, 3GP/MP4, FLV, MKV, MOV, Support up to 3840×2160 Pixels video play back

    Mail attachment support

    ·Viewable document types: .jpg, .tiff, .gif (images); .doc and docx(Microsoft Word); .htm and .html (web pages); .pdf (Preview and Adobe Acrobat); .ppt and .pptx (Microsoft PowerPoint); .xls and .xlsx (Microsoft Excel)

    Languages

    ·Language support for English, French, German, Japanese, Dutch, Italian, Spanish, Russian, Simplified Chinese.....

    ·Keyboard support for English (U.S.), English (UK), (QWERTY), Simplified Chinese (Handwriting and Pinyin)

    Battery and power

    ·Built-in 30W rechargeable lithium-polymer battery, 8000MAH at 3.7V
    ·Up to 10 hours of watching video, surfing the web on Wi-Fi, or listening to music②
    ·Charging via DC charger

    Input and output

    ·HDMI port·(Support HDMI mirror)
    ·Micro USB port for PC connection
    ·Micro SD slot
    ·3.5-mm stereo headphone jack
    ·Built-in speaker x 2
    ·Microphone

    External buttons and controls

    · On/Off, Sleep/wake
    · Home, Back, Menu

    Compatible PC system

    ·Microsoft Windows
    ·With USB 2.0 port

    Environmental requirements

    ·Operating temperature: 32°to 95°F (0°to 35°C)
    ·Nonoperating temperature: -4°to 113°F (-20°to 45°C)
    ·Relative humidity: 5% to 95% noncondensing
    ·Maximum operating altitude: 10,000 feet (3000 m)


    Attached Files:

    • $02.jpg
      File size:
      224 KB
      Views:
      1,276
  2. rplescia

    rplescia Member

    Joined:
    Apr 11, 2012
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    London
    Tablet / Device:
    Visture V10
    I bought this tablet and was delivered last week. Very nice tablet except that it suffers from poor wifi signal. When I say 'poor' wifi signal I mean that I signal drops away completely when just going in to the next room no further away from the router than 3-5 meters. I've researched the issue on the web and found that it seems to be a common problem with the Yuandao N101/Visture V10 tablets that stems from the metallic back plate that detunes the antenna as it has no ground plate. I've emailed Visture about it but they were not particularly helpful. There is a antenna mod that you can do which I found on this forum [MOD] Wifi signal improvement | VonDroid

    Other than that I can hand-on-heart say that this is a very good tablet, awesome battery life, lovely screen, all the apps work and sturdy build quality. I bought the leather case and bluetooth keyboard which are a joy to use.

  3. Dvalin21

    Dvalin21 Senior Member

    Joined:
    Oct 28, 2010
    Messages:
    89
    Likes Received:
    8
    Trophy Points:
    180
    Location:
    NULL
    Last edited: Nov 6, 2012
  4. Dvalin21

    Dvalin21 Senior Member

    Joined:
    Oct 28, 2010
    Messages:
    89
    Likes Received:
    8
    Trophy Points:
    180
    Location:
    NULL
    Also if wouldn't mind posting a video review that would much appreciated :D

  5. rplescia

    rplescia Member

    Joined:
    Apr 11, 2012
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    London
    Tablet / Device:
    Visture V10
    Thanks for the tip, I noticed that Visture also posted a beta version of Android 4.1 for the V10 on their website so I might give that a try and report back. I'm just slightly worried that it may be a hardware issue instead of a software issue, but it can't hurt giving it a go!

  6. Dvalin21

    Dvalin21 Senior Member

    Joined:
    Oct 28, 2010
    Messages:
    89
    Likes Received:
    8
    Trophy Points:
    180
    Location:
    NULL
    I've tried the beta at Visture which is nice, but thecustom is sweeter. Also they are working on a few issues witho that Rom

    • Like Like x 2
  7. shijopj2012

    shijopj2012 Member

    Joined:
    Sep 8, 2012
    Messages:
    5
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    Doha
    Hai..

    Is it worthy to buy? How is the new jelly bean 4.1 on Visture V10? Does it solve the wifi issues? Please answer..

    thanks

  8. Dvalin21

    Dvalin21 Senior Member

    Joined:
    Oct 28, 2010
    Messages:
    89
    Likes Received:
    8
    Trophy Points:
    180
    Location:
    NULL
    Yes, I've been having a blast with this tablet. Super smooth functionality. Also when u get the tab go to freaktab.com and down load the custom ROM. Absolutely great!!!!

    Sent from my SAMSUNG-SGH-T989 using Tapatalk 2

  9. shijopj2012

    shijopj2012 Member

    Joined:
    Sep 8, 2012
    Messages:
    5
    Likes Received:
    0
    Trophy Points:
    60
    Location:
    Doha
    Hai Dvalin,

    So you mean this tablet is worthy to buy. WIFI is catching well and a long stable battery life?

    thanks

    SHIJO

  10. Dvalin21

    Dvalin21 Senior Member

    Joined:
    Oct 28, 2010
    Messages:
    89
    Likes Received:
    8
    Trophy Points:
    180
    Location:
    NULL
    Yes I do mean just that.

    Sent from my SAMSUNG-SGH-T989 using Tapatalk 2
